Conductometre portabile de uz profesional

Conductometre WTW - Germania

conductometru_ProfiLine_Cond_3310

Conductometre portabile de performanta
Modele ProfiLine Cond 3310 si Cond 3110

Conductometre cu data-logger si memorie integrata standarde internationale - farmacopeia

Portable high performance conductivity meter for all standard and special measurements


Pret : la cerere


Certificat de conformitate si validare


Made in EU


solicit oferta personalizata »

Specificatii tehnice
Conductometru portabil de ultima generatie compact, simplu si rezistent la şocuri
Avantaje
– Etanşat 100% antiacvatic , tastatura din silicon cu taste pentru anularea intrarilor gresite
– Timer de calibrare incorporat
– Interfata USB antiacvatica 100% ( doar modelul 3310 )
Seturi de model / livrare

Cond 3110 Set 1 :: Cod produs 2CA101
Conductometru instrument cu display LCD, 2 celule de conductivitate TetraCon 325, solutie standard conductivitate 1413 µS/cm la 25°C, suport senzor, vas, manual utilizare, geanta transport si baterii
Cond 3310 Set 1 Professional :: Cod produs 2CA301
Conductometru instrument cu display grafic LCD, data logger, interfata USB cu software driver, celule de conductivitate TetraCon 325, solutie standard conductivitate 1413 µS/cm la 25°C, suport senzor, vas, manual utilizare, geanta transport si baterii

Conformitate & Certificate
• Certificat de conformitate
• Marcat CE
• Certificat de garantie si post garantie MultiLab Romania
• Centru de service autorizat MultiLab Romania

Cond 3110 & Cond 3310

Model Cond 3110 Cond 3310
Conductivitate
Conductivity
0.0 … 1000 mS/cm ± 0.5 % of val. 0.0 … 1000 mS/cm ± 0.5 % of val.
0.000 … 1.999 µS/cm. K = 0.01 cm–1
0.00 … 19.99 µS/cm. K = 0.1 cm–1
Rezistivitate specifica
Specific resistance
x 0.00 … 20 MΩ cm
Constanta celulei
Cell constants
fixed: 0.475 cm–1
calibratable: 0.450 ... 0.500 cm–1, 0.800 ... 0.880 cm–1
fixed: 0.010 cm–1
calibratable: 0.450 ... 0.500 cm–1, 0.800 ... 0.880 cm–1
adjustable: 0.090 ... 0.110 cm–1, 0.250 ... 25.000 cm–1
Salinitate
Salinity
0.0 ... 70.0 (acc. IOT) 0.0 ... 70.0 (acc. IOT)
TDS x 0 ... 1999 mg/l. 0 bis 199.9 g/l
Temperature - 5.0 ... 105.0 °C ± 0.1 °C – 5.0 ... 105.0 °C ± 0.1 °C
Temperatura de referinta
Tref
20 °C/25 °C 20 °C/25 °C
Temperature Compensation nLF none. nlF. 0.000 ... 3.000 %/K
Interfata x USB
Alimentare 4×1.5V AA sau 4×1.2V NiMh 4×1.5V AA sau 4×1.2V NiMh
Timp operare pana la 1000 h pana la 800 ore sau 150 ore cu grafica luminata
- functie sleep mode folosita pentru prelungirea vietii bateriilor
Dimensiuni 240 x 190 x 80 mm 240 x 190 x 80 mm
Greutate 0.4 Kg 0.4 Kg
Protectie IP 67 IP 67



Main features Cond 3110
Easy to use, rugged conductivity meter with large LCD display for mobile measuring. Individual unit with a short instruction manual, CD-ROM and batteries.
The Cond 3110 is an easy-to-use, reliable conductivity meter with automatic nlF temperature compensation complying with DIN EN 27888 for routine measurements in natural water and wastewater
Suitable for TetraCon 325 or KLE 325
Automatic temperature compensation
Salinity
Measuring reliability
Repeatable measuring results provided by the active, automatic AutoRead function with recognition of stable end values
Safe operation: Automized functions reduce the number of keys (6)
Water-resistant 8-pin socket enables reliable measurements also in humid environments
Easy and reliable
High-visibility display for measuring value ad temperature
Silicone keypad with tangible key click, can also be operated with gloves
For field operation in a case set with the proven electrodes


Main features Cond 3310
Professional, field proven conductivity meter with backlit LCD graphic display for mobile measurement, with data logger, USB interface. Unit with a short instruction manual, CD-ROM and batteries, driver software for USB, cable
The Cond 3310 is a combination of a robust portable meter and a data logger for all who wish to record measuring data automatically and evaluate data on a PC
Waterproof USB interface for fast data transfer
Data output in .csv format
Measuring range 0.001 µS/cm up to 1000 mS/cm
Measuring consistency
Repeatable measuring results provided by the active, automatic AutoRead function with recognition of stable end values
Automatic temperature compensation, can be switched-off
Linear compensation up to 10 %/K
Silicone keypad with tangible key click, optional casing for field operation
GLP/AQA compliant documentation
Large storage for 500 manual and 5000 automatically generated recordings
Transfer of all data in .csv format via USB interface onto PC
On demand formatted export into Excel (MultiLab Importer included in delivery scope or as download)
Flexible and powerful
Measures conductivity, salinity, TDS and specific resistance
Direct data transfer into Excel
Also suitable for measurements complying with Pharmacopeia

Ordering Information :: Order No. 2CA101
Cond 3110 Set 1 Easy-to-operate, robust conductivity meter with large LCD-display, for mobile routine applica-tion for 2- and 4-electrode cells. Meter with carry case including 2-electrode conductivity cell TetraCon 325, standard solution 1413 µS/cm at 25 °C, stand, beaker, short instruction manual, CD-ROM and batteries.
Cond 3310 Set 1 Professional :: Order No. 2CA301
field proven conductivity meter with backlit graphic display for mobile applications including data logger, USB-interface. Meter with carry case including 4-electrode conductivity cell TetraCon 325, standard solution 1413 µS/cm at 25 °C, stand, beaker, short instruction manual, CD-ROM and batteries, driver software for USB, cable.

Accesorii optionale

Celula de conductivitate cu senzor de temperatură integrat

Model Celula de conductivitate Domeniu de masura Tmp. Cod. prod.
TetraCon® 325 4 electrode graphite cell, 1.5 m cable 1 µS/cm ... 2 S/cm* 0 .. 100°C 301960
TetraCon® 325-3 4 electrode graphite cell, 3 m cable 1 µS/cm ... 2 S/cm* 0 .. 100°C 301970
TetraCon® 325-6 4 electrode graphite cell, 6 m cable 1 µS/cm ... 2 S/cm* 0 .. 100°C 301971
TetraCon® 325-10 4 electrode graphite cell, 10 m cable 1 µS/cm ... 2 S/cm* 0 .. 100°C 301972
TetraCon® 325-15 4 electrode graphite cell, 15 m cable 1 µS/cm ... 2 S/cm* 0 .. 100°C 301973
TetraCon® 325-20 4 electrode graphite cell, 20 m cable 1 µS/cm ... 2 S/cm* 0 .. 100°C 301974
TetraCon® V 4 electrode graphite cell, Vario Cond 1 µS/cm ... 2 S/cm* 0 .. 100°C 301990
KLE 325 2 electrode graphite cell, 1.5 m cable 1 µS/cm ... 20 mS/cm* 0 .. 100°C 301995

Dispozitive si ustensile

Model Descriere cod produs
STH 650 Tripod 109809
E-SET Standard de calibrare
Trace Calibration and control standard
300752
6R/SET/LAB1 Kit teste de rezistenta
Resistance test set
302870
D 3Sen pahar de masurare in debit
Flow vessel for field measurements
903842



Conductometre HANNA - SUA


Conductometru portabile multifunctional
Model HI 98192

Instrument pentru EC, rezistivitate, TDS, salinitate si temperatura

Professional Waterproof EC/TDS/Resistivity/Salinity Meter


Pret : la cerere


Certificat de conformitate si validare


solicit oferta personalizata »

Specificatii tehnice
Conductometru portabil conceput pentru a oferi rezultate si acuratete de laborator în conditii dificile, industriale.
Conformitatea cu standardul USP face ca instrumentul sa fie ideal pentru masuratori de determinare a puritatii apei.
Aparatul este prevazut cu o serie de noi caracteristici de diagnosticare ce permit utilizatorului sa îmbunatateasca semnificativ fiabilitatea masuratorilor.
Instrumentul permite de asemenea efectuarea masuratorilor de rezistitivitate, TDS si salinitate. Pentru salinitate sunt disponibile trei moduri de masurare: % NaCl, Salinitate practica si Apa de mare naturala.

Conformitate & Certificate
• Certificat de conformitate
• Marcat CE
• Certificat de garantie si post garantie MultiLab Romania
• Centru de service autorizat MultiLab Romania

Main features
The HI-98192 is a waterproof, portable conductivity meter that has an expanded conductivity range from 0.000µS/cm to 400 mS/cm, as well as TDS, resistivity and three salinity scales. This meter automatically recognises the probe type (two or four ring) and allows the user to adjust the nominal cell constant.
HI-98192 is also ready to perform all three stages USP <645> method required for EC measurement of ultrapure water. Choose from seven memorised standards and obtain up to a five point conductivity calibration. For salinity (% range), HI-7037 standard allows users to make a one point calibration.
EC and TDS measurements are fully customisable and include: cell constant selection between 0.010 and 10.000, selection of linear or natural water (non-linear) or no temperature compensation (for actual conductivity reading), configurable temperature compensation coefficient range from 0.00 to 10.00%/°C, choice of reference temperatures of 15°C, 20°C and 25°C, and a selectable TDS factor between 0.40 and 1.00.
Quick connect probe
The HI-763123 four ring platinum conductivity probe features a quick connect DIN connector to make attaching and removing the probe simple and easy. Data Logging
The HI-98192's allows users to store up to 400 log-on demand samples or 1000 lot logging samples that can be later transferred to a PC with the HI-920015 USB cable and HI-92000 software.
GLP and On-Screen Help
Comprehensive GL data is directly accessible by pressing the GLP key; the contextual help menu can be accessed to obtain on-screen information and assistance at the touch of a button.
Key Features
IP67 rated waterproof, rugged enclosure
Salinity readings - Salinity can be displayed as % NaCl, seawater scale (ppt) or practical salinity scale (PSU)
Calibration - perform up to a five point calibration for enhanced accuracy
Automatic temperature compensation
Configurable temperature coefficient range from 0.00 to 10.00% °C
Approximately 100 hour battery life powered by (4) 1.5V AA batteries
Four ring platinum probe - this probe can cover low EC samples to 1000 mS/cm (actual EC)
Supplied with
HI-763123 platinum four ring conductivity/TDS probe
HI-7031M
HI-7035M
Rugged carrying case
100mL plastic beaker (2)
HI-92000 PC software
HI-920015 micro USB cable
Batteries
Instruction manual
Quality certificate

date tehnice

Domeniu EC
EC Range
0.000 to 9.999 μS/cm*; 10.00 to 99.99 μS/cm; 100.0 to 999.9 μS/cm; 1.000 to 9.999 mS/cm; 10.00 to 99.99 mS/cm; 100.0 to 1000.0 mS/cm (actual conductivity; temperature compensated to 400 mS/cm)
Rezolutie EC
EC Resolution
0.001 μS/cm; 0.01 μS/cm; 0.1 μS/cm; 0.001 mS/cm; 0.01 mS/cm; 0.1 mS/cm
Acuratete EC
EC Accuracy
±1% of reading (±0.01 μS/cm or 1 digit, whichever is greater)
Calibrare EC
EC Calibration
automatic up to five points with seven memorized standards (0.00 μS/cm, 84.0 μS/cm, 1.413 mS/cm, 5.00 mS/cm, 12.88 mS/cm, 80.0 mS/cm, 111.8 mS/cm)
Domeniu TDS
TDS Range
0.00 to 99.99 ppm; 100.0 to 999.9 ppm; 1.000 to 9.999 ppt (g/L); 10.00 to 99.99 ppt (g/L); 100.0 to 400.0 ppt (g/L) TDS Resolution 0.01 ppm; 0.1 ppm; 0.001 ppt (g/L); 0.01 ppt (g/L); 0.1 ppt (g/L)
Acuratete TDS
TDS Accuracy
±1% of reading (±0.05 mg/L (ppm) or 1 digit, whichever is greater)
Domeniu rezistivitate
Resistivity Range
1.0 to 99.9 Ω•cm; 100 to 999 Ω•cm; 1.00 to 9.99 KΩ•cm; 10.0 to 99.9 KΩ•cm; 100 to 999 KΩ•cm; 1.00 to 9.99 MΩ•cm; 10.0 to 100.0 MΩ•cm
Rezolutie rezistivitate
Resistivity Resolution
0.1 Ω•cm; 1 Ω•cm; 0.01 KΩ•cm; 0.1 KΩ•cm; 1 KΩ•cm; 0.01 MΩ•cm; 0.1 MΩ•cm*
Acuratete rezistivitate
Resistivity Accuracy
±1% of reading (±10 Ω or 1 digit, whichever is greater)
Domeniu salinitate
Salinity Range
% NaCl : 0.0 to 400.0%; practical salinity: 0.00 to 42.00 (PSU); natural seawater scale - UNESCO 1966: 0.00 to 80.00 (ppt)
Rezoultie salinitate
Salinity Resolution
0.1%; 0.01
Acuratete salinitate
Salinity Accuracy
±1% of reading
Calibrare salinitate
Salinity Calibration
max. one point only in % range (with HI7037 standard); use conductivity calibration for all other ranges
Domeniu temperatura
Temperature Range
-20.0 to 120.0°C
Rezolutie temperatura
Temperature Resolution
0.1°C
Acuratete temperatura
Temperature Accuracy
±0.2°C;(excluding probe error)
Calibrare temperatura
Temperature Calibration
one or two points
Compensare temperatura
Temperature Compensation
noTC, Linear (-20 to 120 °C), Non Linear - ISO/DIN 7888 (-0 to 36 °C)
Moduri de masurare
Measurement Modes
autorange, autoend, lock and fixed range
Temperatura de referinta
Reference Temperature
15°C, 20°C and 25°C
Coeificint de temperatura
Temperature Coefficient
0.00 to 10.00 %/°C
Factor TDS
TDS Factor
0.40 to 1.00
Sonda
Electrode/Probe
HI763133, four ring conductivity/TDS probe with internal temperature sensor and 4 m (13.2’) cable (included)
Logare
Log-on-demand
400 samples; lot logging: 5, 10, 30 sec, 1, 2, 5, 10, 15, 30, 60, 120, 180 min (max 1000 samples)
Profile memorizate
Memorized Profiles
up to 10
Conectare PC
PC Connectivity
opto-isolated USB with optional HI 92000 software and micro USB cable
Tip baterie / Durata
Battery Type/Life
1.5V AA batteries (4) / approximately 100 hours of continuous use (without backlight), 25 hours with backlight
Inchidere automata
Auto-off
user selectable: 5, 10, 30, 60 min or can be disabled
Conditii de operare
Environment
0 to 50°C; RH 100% (IP67)
Dimensiuni
Dimensions
185 x 93 x 35.2 mm
Greutate
Weight
400 g
Continut pachet HI 98192 este livrat cu sonda de conductivitate HI 763133 cu senzor de temperatura încorporat, solutie de calibrare HI 7031M (1413 μS/cm), HI 7035M (118.8 μS/cm); 2 pahare de 100 mL, software HI 92000, cablu micro-USB, 4 baterii 1.5V AA, geanta pentru transport si instructiuni de utilizare.
Ordering Information HI98192 is supplied with HI763133 conductivity probe, HI7031M 1413 μS/cm calibration solution (230 mL), HI7035M 111.8 mS/cm calibration solution (230 mL), 100 mL plastic beaker (2), HI92000 PC software, HI920015 micro USB cable, 1.5V AA batteries (4), instruction manual, quick start guide, quality certificate and HI720192 rugged carrying case.



Accesorii optionale
