Analizor de textura multiparametric


Aparat multifuctional pentru determinarea proprietatile de textura
CT3 :: Brookfield

Analizor de textura de mare performanta

High Performance Texture Analyzer


produsul poate fi achizitionat si prin SEAP


solicit oferta personalizata »


analizor textura paine Video »

Avantaje
Permite testarea unei game foarte largi de materie prime si produse finite, agricole, farmaceutice si alimentare (ex. carne, branzeturi, iaurt, produse de panificatie si patiserie, fructe si legume, jeleuri, ciocolata,halva, geluri, etc)
Este utilizat pentru teste de compresie, singulare si multiple, pentru analiza profilului textural, pentru teste de extensie, bloom test pentru gelatina, etc
Testele de compresie permit introducerea unor probe de pana la 22.5 cm inaltime
Instrumentul poate fi dotat cu o celula de sarcina care sa permita realizarea testelor cu sarcini de pana la 50 kg
Analizorul de textura are disponibil optional software-ul TexturePro CT care permite colectarea datelor si analiza acestora, reprezentarea grafica in timp real, calcularea parametrilor de interes (elasticitate, masticabilitate, duritate, etc) si controlarea instrumentuluicu ajutorul PC-ului
Domeniul de setare a vitezei: 0.01 mm/s ... 10 mm/s, cu o acuratete de 0.1%

Aplicatii:
Caracteristici ce pot fi masurate (cu ajutorul unor accesorii adecvate): Elasticitate, rezilienta, adeziune, coeziune, rezistenta la rupere, rezistenta la tractiune, rezistenta la incovoiere, alungirea, rezistenta la mestecare etc.
Cateva exemple de produse la care se poate masura textura:
Produse farmaceutice, paine, paste fainoase, prajituri, biscuiti, dulciuri, produse lactate, fructe si legume, carne, peste, oua etc.

Date tehnice

Model CT3
Domeniu de viteza 0.01 - 0.1 mm/s (increments 0.01mm/s)
0.1 - 10 mm/s (increments 0.1mm/s)
Acuratete vitezei ±0.1% of set speed
Pozitia / miscare 0 - 101.6mm
Rezolutie pozitia / miscare 0.1mm* and 0.01mm (cu softul TexturePro CT)
Acuratete pozitia / miscare 0.1mm

Certificate
Certificat de conformitate
Certificat de garantie; post garantie si service ISO 14001 si ISO 9001 / MultiLab Romania

The CT3 is a low cost, but powerful, universal testing machine that offers both compression and tensile testing. It can calculate, through compression and tensile data, a number of physical properties that have proven to be highly correlated to human sensory evaluation of food and other consumer products. With six built-in test modes and ten memory slots for operator-protected tests with administrator rights, a wide choice of accessories and an optional software package, the CT-3 is perfect for most any physical testing requirements.
The CT3 performs like a high end texture analyzer but at a fraction of the cost. Its uses can expand with your applications - or your testing imagination! The CT3's easy-to-operate design will have your R&D and QC up and running in no time.
Main features
Choice of five load ranges up to 50kg
A variety of probes and accessories for new application opportunities
Choice of two adjustable base tables allows for for versatility of sample testing
Six available test modes plus a calibration check
Stores up to 10 additional customized test methods
Easy-to-read display and easy-to-use, intuitive controls
Provides a "real life" insight into physical properties
21CFR compliant with optional TexturePro software
Texture Profile Analysis (TPA) specific for the Food Industry
USB and RS232 outputs
Conforms fully with GME and GMIA monographs for gelatin Bloom assessment; includes built-in Bloom Test function
Gelatin Bath System available for sample conditioning
Easiest-to-use Texture Analyzer in its class
Supplied with Texture Loader software to allow creation of up to 10 customized tests
Can be used with optional software, TexturePro CT, to easily create custom reports and graphs

Technical Data

Model CT3
Speed range 0.01 - 0.1 mm/s (increments 0.01mm/s)
0.1 - 10 mm/s (increments 0.1mm/s)
Speed accuracy ±0.1% of set speed
Position range 0 - 101.6mm
Position resolution 0.1mm* and 0.01mm (when used with TexturePro CT software)
Position accuracy 0.1mm

Parameters measured
• Ripeness
• Yield Point
• Spreadability
• Tackiness
• Consistency
• Relaxation
• Pliability
• Adhesiveness
• Firmness
• Elasticity
• Hardness
• Cohesiveness
• Burst Strength
• Breaking Point
• Fracturability
• Gel Strength



Fixtures & Accesories Description
Standard Probe Kit
with a wide range of probes to suit almost every test application
Includes the following probes:
60 degree cone 30mm dia
12.7mm cylindrical w/rounded edge
60mm wide clear acrylic w/knife edge
1.0mm dia needle probe 43mm long
12.7mm cylindrical w/sharp edge (AACC std for bloom test)
25.4mm dia cylindrical w/sharp edge 35mm long
45 degree cone 30mm dia
30 degree cone 24mm dia
12.7mm dia ball probe
50.8mm dia cylindrical w/rounded edge 20mm long
0.33mm cutting wire in 40mm wide aluminum frame
2mm cylindrical probe 20mm long
38.1mm cylindrical w/rounded edge 20mm long
6mm cylindrical probe 35mm long
25.4mm dia ball probe
4mm dia cylindrical probe
storage case
Texture Pro Software
powerful, easy-to-use software! Collect data and perform detailed data analysis with real time graphic plotting during the test. Easily create custom reports and graphs right from the menu screen.
Easily select test parameters
Database file structure for easy-to-manage files
Sample identification set-up screen helps new operators quickly get started; test method setup defines a variety of parameters
Intuitive set up for test methods and database file structures in a single window
Data is captured as a graph and stored in tabular database format Advanced data analysis with built-in parameter calculations such as springiness, chewiness, hardness and much more!
Evaluate mean and standard deviation of each result parameter for up to 30 samples 21CFR compliant with optional TexturePro software
Cosmetic Fixtures A-DEC Dual Extrusion Cell for either forward or backward extrusion of lotions, creams and other similar products.
TA-HCF Hair Compatibility Fixture measures the effect of products, such as shampoo and conditioner, on the combability of hair.
TA-LC Lipstick Cantilever Test Fixture allows imitative tests on lipstick and similar products to quantify strength of product.
TA-EP Eye Pencil Test Fixture measures hardness of cosmetic pencil tips for eye or lip lining products and can also be used for artistic type pencil tips.
TA-STF Spread Test Fixture quantifies the spread force of a material. Comes with 1 male cone probe, 5 five samples cups and 1 sample cup holder.
TA-TEF The squeezing force to extrude creams and ointments is quantified using a support fixture to hold the tube in place while pressing down with a finger-shaped blade.
A-P-KIT2 Standard Probe Kit has variety of cylindrical (8), cone (3), ball (2), needle (1), knife-edge (1), and wire cutting (1) probes. Complies with BS and AACC.
Food Fixtures TA-10 GMIA & GME Probe and spec Bloom bottle TA-GBB-2 sold in package of twelve bottles.
TA-MCF The Multiple Chip Fixture is used for testing the penetration or firmness of multiple chips/french fries.
TA-CSF Circular Support Fixture provides support for round samples and retains any potential fluid expressed during the test.
TA-AVJ Adjustable Vice Fixture for holding small samples for puncture tests. Good for jelly beans, gum drops, etc.
TA-MTP Magness-Taylor Probes puncture test measures hardness of fresh fruits and vegetables.
TA-CJ Confectionary Fixture for holding candies and similar products for penetration testing.
TA-KF Kieffer Dough and Gluten extensibility fixture quantifies maximum force and distance needed to break the sample.
TA-JPA Junior Punch Fixture is for punching through flat samples; 12.7mm max. diameter probe. Hole in fixture is 14mm.
TA-TPB Three Point Bend fixture is used with TA7 blade from the general probe kit. Small scale version (TA-JTPB) also available.
TA-JTPB Small scale version of a three point bend fixture. Used with TA7 blade from general probe kit.
TA-TRF Tortilla Roll-up Fixture evaluates changes in corn tortilla texture — per AACC technical method — by measuring the force required to roll up a tortilla.
TA-CKA Craft Knife Adapter cuts cleanly into and through material with minimum deformation of the sample.
TA-52 MOHRS Shear Blade used for cutting tests, especially meat, poultry, fish or similar products.
TA-MP Mesh Probe quantifies the consistency of products such as mayonnaise and yogurt.
TA-STF Spread test fixture quantifies the force to spread a material, such as butter, on a surface.
TA-DSJ Dough Stickiness Fixture is the standard test for measuring dough stickiness; important for processing raw dough.
TA-DE Dough Extensibility Fixture for holding sheet of raw dough or flat bread to measure breaking point of stretched sample.
TA-CTP Compression Top Plate for applying uniform compression forces on samples up to 4x6 inches (10x15cm).
TA-FMBRA Standard dough pot set for preparing dough samples and measuring dough firmness.
TA-AACC36 AACC spec probe for measuring bread firmness and performing texture profile analysis (TPA).
TA-VBJ Volodkevich Bite Jaws for testing bite force of meat products using shear cutting test.
TA-PTF Pizza Tensile Fixture quantifies cooked pizza firmness by measuring the tensile force and deformation distance to break sample
TA-NTF Noodle Tensile Fixture to evaluate noodle quality.
TA-OC Ottawa Cell for extruding assorted soft samples, like pasta or diced fruit and vegetables.
TA-SBA Shear Blade for products where a cutting-shear test is meaningful: meat, fish, sausage, etc.
TA-SFF Spaghetti Flexure Fixture quantifies flexure characteristics of uncooked spaghetti and other dry pastas.
TA-BEC Back Extrusion Cell for measuring consistency of applesauce, pudding, yogurt or similar products.
TA-KSC Kramer Shear Cell for shear-cutting and extrusion testing on small fruits and vegetables such as grapes, figs, corn and beans.
TA-PFS-C Pasta Firmness and Stickiness Fixture measures pasta and like products.
TA-CEF Cheese Extensibility Fixture measures the extensibility of the sample, such as molten cheese, to break point.
TA-DEC Dual Extrusion Cell for either forward or back extrusion of fruit puree, pudding, yogurt or similar products.
TA-JMPA Multiple Probe Assembly consisting of nine 3mm probes and base plate designed to hold nine small samples of irregular geometry.
TA-PFS Pasta Firmness and Stickiness Fixture measures pasta and like products.
TA-WSP Wire Shear Plate cuts through the sample. Good for products with significant stickiness like cheese and butter.
TA-P-KIT3 Curd probe kit with one each: 5mm (TA46), 8 mm (TA47) and 10 mm (TA48) probe.
TA-P-KIT2 Standard Probe Kit has variety of cylindrical (8), cone(3), ball (2), needle (1), knife-edge (1), and wire cutting (1) probes. Complies with BS and AACC.
Materials Fixtures TA-JPA Junior Punch Fixture is for punching through flat samples; 12.7mm max. diameter probe. Hole in fixture is 14mm.
TA-PTF Pizza Tensile Fixture quantifies cooked pizza firmness by measuring the tensile force and deformation distance to break sample
TA-RCA Roller Cam Accessory Grips measure the tensile strength and tear characteristics of material such as polymer films.
TA-AVJ Adjustable Vice Fixture for holding small samples for puncture tests. Good for jelly beans, gum drops, etc.
TA-DGA Dual Grip Assembly for tensile testing of thin films or integrity of seals.
TA-FSF Film Support Fixture for puncture test to measure strength of fine films.
TA-ATT Adhesive Tack Tester for measuring stickiness of pressure sensitive adhesive materials such as aluminum foil tape.
TA-BEC Back Extrusion Cell for measuring consistency of applesauce, pudding, yogurt or similar products.
TA-EP Eye Pencil Test Fixture measures hardness of cosmetic pencil tips for eye or lip lining products and can also be use for artistic type pencil tips.
TA-LTT Loop Tack Test measures the adhesive strength of pressure sensitive tape and stickers according to ASTM D6195.
TA-TSF Tape Stickiness Fixture measures adhesive force to pull tape off of a surface. Multiple tape samples can be tested simultaneously for average value.
TA-ATT Adhesive Tack Tester for measuring the stickiness of pressure sensitive adhesives such as tape or labels.
TA-GPJ General Peeling Jig measures the adhesive strength needed to remove the lid from a sealed container at 0°, 45° and 90° angles.
TA-PF90 90° Peel Fixture measures the adhesive strength to pull a tape off of a rigid surface using force at a 90° angle.
TA-P-KIT2 Standard Probe Kit has variety of cylindrical (8), cone(3), ball (2), needle (1), knife-edge (1), and wire cutting (1) probes. Complies with BS and AACC.
Pharmaceutical Fixtures TA-DEC Dual Extrusion Cell for either forward or back extrusion of fruit puree, pudding, yogurt or similar products.
TA-JMPA Multiple Probe Assembly consisting of nine 3mm probes and base plate. Designed to hold nine small samples of irregular geometry such as peas, corn, nuts or dried fruit.
TA-DGA Dual Grip Assembly for tensile testing of thin films or integrity of seals.
TA-FSF Film Support Fixture for puncture test to measure strength of fine films.
TA-ATT Adhesive Tack Tester for measuring stickiness of pressure sensitive adhesive materials such as aluminum foil tape.
TA-STJ Syringe Test Fixture for measuring the force required to push or pull syringe plunger. Important to pre-filled syringe market or manufacturers of custom syringe products.
TA-BPS Blister Pack Support Fixture is used to measure the force required to remove the tablet from its blister pack.
TA-MDI Meter Does Inhaler Fixture measures the push-button force to actuate the inhaler.
TA-TCA Table Coating Adhesion Fixture measures the adhesion force of a tablet coating to a tablet.
TA-CLT Capsule Loop Tensile Test Fixture is used to measure the force required to split one half of a hard gel capsule.
TA-MA Muco Adhesion Test Fixture quantifies tablet adhesiveness to a mucosal surface by simulating body and temp conditions and force needed to pull tablet away from surface.
TA-BLS Bilayer Shear Test Fixture uses guillotine blade to separate bilayer tablet while measuring shear strength.
TA-RT Raft Tester measures alginate raft strength by pulling a wire raft hook out the a sample material.
TA-P-KIT2 Standard Probe Kit has variety of cylindrical (8), cone(3), ball (2), needle (1), knife-edge (1), and wire cutting (1) probes. Complies with BS and AACC.
Bloom Sample Bottles and Stoppers / 12 PCS TA-GB8-2 - GMIA approved gelatin bloom bottle with stoppers.
Calibration Weights/Strip weight sets used to check the calibration of the CT-3 Texture Analyzer. Each set comes complete with appropriate weights, carry case and a verification certificate traceable to NIST standards.
TA-CW-100C : Total Mass 100g
TA-CW-1000C : Total Mass 1000g
TA-CW-1500C : Total Mass 1500g
TA-CW-4500C : Total Mass 4500g
TA-CW-10KG : Total Mass 10kg
Bloom Test Calibration Strips are also available to check load calibration
Cylindrical, Conical and Spherical Probes
Water Baths Consists of one TC-450MX and one TC-450SD water baths and one TC-351 refrigerated chiller. System is used by attaching TC-351 to one bath set to 10C. The second bath is set to 60C providing rapid transfer between the thermal environments necessary for conditioning gelatin for Bloom testing. Each bath has 29L reservior and capacity for twelve (12) gelatin jars and a removeable rack for easy handling.
Knife Edges & Wires
