Aparat digital automat CBO5
Capacitate cu 6 sau 10 senzori de masurare
Model HI993310

Aparat pentru msurare conductivitate direct in sol sau in lichide

BOD equipment for Biochemical Oxygen Demand in water and wastewater


produsul poate fi achizitionat si prin SEAP


solicit oferta personalizata »

Sistem CB05 pentru determinarea consumului de oxigen necesar pentru descompunerea biochimica a substantelor organice la temperatura si timpul standard timp de 5 zile

BOD-Sensor System 6 si BOD-System 10
Sistemul BOD Sensor System 6 (6 sticle cu senzori) si 10 (10 sticle cu senzori) in conformitate cu toate normele de protectie pentru mediu cat si pentru operator
Valorile sunt exprimate si afisate direct in mg/l
Valorile CBO5 (ppm) pot fi afisate in fiecare zi, chiar si dupa perioada standard de 5 zile.
Dupa determinarea valorilor de BOD5 este posibila si determinarea BOD-ului total.
Materialul de constructie este din otel inox protejat un strat de epoxy ceea ce-i confera o rezistenta foarte buna impotriva coroziunii chimice. Motorul permite o agitare continua, fara riscul unor intreruperi sau supraincalziri ceea ce ar putea afecta rezultatele determinarilor BOD

Sistem in configuratie completa:
• unitate de agitare cu 6 sau 10 posturi
• 6 / 10 senzori BOD
• 6 / 10 suporti pentru absorbtia dioxidului de carbon
• 6 / 10 sticlute pentru BOD
• 6 / 10 agitatoare magnetice
• manual si metode de operare

Pentru determinarea BOD –ului este necesar utilizarea unei termostat cu racire (incubator)
Echipamentul este prevazut cu 2 manere laterale, ceea ce permite o introducere usoara si rapida in incubator

Date tehnice
- Date memorate: 5 valori BOD la intervale ciclice de 24 ore
- Afisaj digital cu 3 digiti cu o inaltime de 7 mm
- Scale: 90, 250, 600, 999 ppm BOD, valori mai mari dupa dilutie
- Alimentare senzor BOD: 2 baterii de litiu (250 mAh) tip CR2430
- Durata bateriilor: aproximativ 2 ani
- Clasa de protectie: 3 IEC 1010
- Clasa de protectie: IP 44 IEC 529
- Temperatura de stocare admisibila: -25…+650C
- Putere: 2 W
- Greutate: 3 kg
- Dimensiune:
- System BOD-6 :: 270x300x185 mm
- System BOD-10 :: 432x300x165 mm

Ghid Comanda

Model Descriere Cod prod.
Sistem BOD6 Set complet Include: S10220136
  Statie de agitare cu 6 locuri (cu sticle si bare magnetice de agitare) F10230270
  Sensor BOD (with KOH traps) F102B0133
Sistem BOD10 Set complet Include:
  Statie de agitare cu 10 locuri (cu sticle si bare magnetice de agitare) F10230280
  Senzor BOD with KOH traps F102B0133
Sensor BOD Senzor BOD F102B0133
Set de senzori BOD Include:
  - Sensor BOD (with KOH traps) F102B0133
  - Sticla BOD 10001107
  - Bara magnetica pt. Agitare de 6x35 mm A00001056



Main Features
BOD equipment is designed for Biochemical Oxygen Demand (BOD analysis) in water and wastewater samples according to official organizations.
Measure BOD according to Standard Methods 5210 D
Precise Control
Measurement on scales of 90, 250, 600 and 999 ppm BOD
Higher values can be measured by diluting the sample
Models with stirring stations offer VELP stirring quality
Extremely Practical
Fits directly on the bottle containing the sample
Automatically stores 5 BOD values at 24-hour intervals
Enables analysis to continue over the weekend
Results directly readable at any time, even after five days
Direct readout in mg/l (ppm)
Compact stirring stations
Priority to Safety
IP 54 protection against particle and liquid ingress
Class 3 IEC 1010 conformity
Choice of Models
BOD Sensor Set a ready-to-use solution for individual BOD analysis only
BOD Sensor a dark glass bottle, an alkali holder and a stirring bar
BOD Sensor Set is designed for use with the VELP MST stirrer
BOD Sensor System 6 a complete package for 6 tests
6-position stirring station, 6 BOD Sensors, dark glass bottles, alkali holders & stirring bars
BOD Sensor System 10 a complete package for 10 tests
10-position stirring station, 10 BOD Sensors, dark glass bottles, alkali holders & stirring bars
Stirring stations are designed for simple handling, ensuring the VELP stirring quality
Up to 5 stirring stations with 6 positions (30 samples) or 3 stirring stations with 10 positions
(30 samples) can be placed in a VELP incubator (FOC 215E)

Technical specifications

GENERAL FEATURES
Construction material: technopolymer
Power: - BOD Sensor
- BOD Sensor Set
- BOD Sensor System 6 2 W
- BOD Sensor System 10 2 W
Power supply: BOD Sensor 2x3V lithium batteries
BOD Sensor Set 2x3V lithium batteries
BOD Sensor System 6 230 V / 50-60 Hz
BOD Sensor System 10 230 V / 50-60 Hz
Dimensions (WxHxD): BOD Sensor 55x71x73 mm
BOD Sensor Set 75x230x75 mm
BOD Sensor System 6 270x300x185 mm
BOD Sensor System 10 432x300x165 mm
Weight: BOD Sensor 0,08 kg
BOD Sensor Set 0,4 kg
BOD Sensor System 6 2,3 Kg
BOD Sensor System 10 3 Kg
Performance
Reading value: mg/l (ppm) directly on the display
Measurement by electronic pressure probe
Bottle total capacity: 500 ml
Stored data: 5 BOD values at 24h intervals
BOD values: directly on the display at any time also after the standard 5 days period
BOD last determination: possible Scales: 90, 250, 600, 999 ppm BOD. Higher values after dilution
Display: digits 3 LED
Safety class: 3 IEC 1010 Electronic protection degree CEI EN 60529: IP 54



Optional accessories

Descriere Cod Produs
Incubator cu racire 120 lit
Model FTC 120
Temperatura constanta la 20 °C
Capacitate: 3 x Sistem BOD6 sau 2 x Sistem BOD10
F10300300
Incubator cu racire 120 lit
Model FOC 120E
Temperatura reglabila 3°C la 50.0 °C
Capacitate: 3 x Sistem BOD6 sau 2 x Sistem BOD10
F10300310
Set 6 sticlute negre de 500 ml Cod prod. 10001107
KOH trap 10000904
Set de 6 bare magnetice de 6x35 mm A00001056
Teblete de teste si control. 10 buc/cutie A00000136
