Plita de incalzire cu infrarosu 550°C

Plite de incalzire cu IR

ro Aparatura si dispozitive de incalzire » Plite electrice » Plita de laborator cu incalzire IR :: Model SLK 12

uk Heating Equipments » Electrical Hotplates » IR Laboratory hotplate :: Model SLK 12




Plita de incalzire cu control electronic

Model SLK 12 / SI Analytics

Aplicatii: laborator, industrie si uz general

Plita de incalzire cu IR
incalzire pana la 550 °C

Caracteristici generale
Plita electrica cu suprafata din sticla ceramica cu o impermeabilitate mare IR; rezistenta chimica foarte buna in special la acizi si la fluctuatiile de temperatura
Suprafata de incalzire este rotunda ceea ce permite incalzirea vasului partial sau complet
Doua zone pentru vase de dimensiuni mici sau mari
Carcasa din otel inoxidabil
Indicator LED pentru caldura reziduala si operare sigura
Interfata pentru conexiune optionala pentru aer comprimat permite operarea in medii de lucru agresive
Marcaj CE; compatibilitate electromagnetica conform cu Directiva 2004/108/EEC
Indicatoare: 2 LED-uri pentru modul de operare si pentru incalzirea reziduala
Clasa de protectie: IP-1 siguranta pentru dispozitivele electrice (nu este potrivit pentru utilizarea in medii explosive)
Conditii de operare si stocare: temperature ambianta +10 .. +40°C

Date tehnice

Sursa de incalzire: infrarosu
Temperatura maxima : 550°C
Zone incalzire: Ø110, Ø180Ø mm
Putere: 1700 W
Clasa de protectie: IP 1
Material plita: sticla ceramica
Dimensiune plita: 330 x 300 mm
Dimensioni: 330 x 73 x 300 mm
Alimentare: 230 V, 50/60 HZ
Greutate: 5 kg
Cod produs: SLK12230

Solicit oferta de pret »

Precision digital Hotplate
Laboratory hotplate meets high demands in quality and robustness. Even in very rough environments one can count on its dependability

Main Features
The pore-free glass-ceramics surface (easy-to-clean) is highly resistant against chemical influences and temperature fluctuations
The glass-ceramics surface has a high infrared permeability and hence is exceptional economic saving energy and time
The heating surface is throughout planar and offers not heated border areas. This allows the vessel to be heated partially or completely removed off the hotplate
High-quality, unpainted and nonsensitive stainless steel casing
Heating area with two zones (230 V) for small and bigger vessels
Indicator LED for residual heat for safe operation
An optional compressed air connection allows operation in highly aggressive environment

Technical specifications
CE Mark: Electromagnetic compatibility according to Council Directive 2004/108/EEC; low-voltage directive according to Council Directive 2006/95/EEC
Display: 1 LED for operating mode display, 1 LED for residiual heat display
Mains connection: Mains cable with safety plug for 230 Volts version
Safety measure: Device of Protection Class I, manufactured and tested in accordance with safety measures for electric devices; not suitable for use in explosive environments
Power supply: 230 V~, 50 / 60 Hz
Casing material: stainless steel
Climate: + 10 ... + 40 °C for operation and storage
Atmospheric humidity: in accordance with EN 61 010, Part 1: maximum relative humidity 80 % for temperatures up to 31 °C, decreasing linearly to 50 % relative humidity at a temperature of 40°C

Technical specifications
Dimension: 330 x 73 x 300 mm
Surface temperature: max 550 °C
Surface dimension: 330 x 300 mm
Surface material: Glass ceramics
Heating area: approx. Ø110, Ø180Ø mm
Heating source: Infrared
Heating power: 1700 W
Weight: 5 Kg
Product code SLK12230
