Oxigenometre WTW - Germania


Oxigenometre portabile de performanta

Seria ProfiLine 3000 :: Modele Oxi3205 Oxi3210 Oxi3310 si Oxi3315

Oxigenometre cu data-logger si memorie integrata

standarde internationale - GLP/AQA - farmacopeia

Portable high performance conductivity meter for all standard and special measurements


Pret : la cerere


Certificat de conformitate si validare


Made in EU


solicit oferta personalizata »

Specificatii tehnice
Aparat portabil pentru masurarea oxigenul dizolvat de ultima generatie compact, simplu si rezistent la şocuri

Avantaje
• Oxigenometre antiacvatice, submersibile, cu baterii, afisare a temperaturii, memorie de date
• Functionare conform GLP
• Afisare automata a temperaturii
• Compensare a presiunii si salinitatii
• Alimentare la baterie si optional la retea (adaptor)

Date tehnice

Model ProfiLine Oxi 3205 ProfiLine Oxi 3210 ProfiLine Oxi 3310
• Domeniu / O2 Concentratie
•• Rezolutie / O2 saturatie
••• Acuratete / O2 presiune partiala
•••• Temperatura
• 0.00 .. 20.00 mg/l (20.0 mg/l*) ±0.5 % din valoare;
•• 0 .. 90 mg/l ±0.5 % din valoare 0.0 .. 200.0 % (200 %*) ±0.5 % din valoare; 0 .. 600 % ±0.5 % din valoare
••• 0.0 .. 200.0 mbar (200 mbar*) ±0.5 % din valoare, 0 .. 1250 mbar ±0.5 % din valoare
•••• -5.0 .. +105.0 °C ±0,1 °C
Identificare / scanare
Compensarea temperatura mai buna de 2% la 0 .. +40 °C
Compensarea presiunii aerului automat cu senzor de presiune (500 .. 1100 mbar)
Protocol de calibrare digital digital digital
Corectia salinitatii / SAL 0 sau 35 fix automat de la 0,0...70,0 ajustabila via display
Calibrare Calibrare rapida OxiCal cu OxiCal-SL sau OxiCal - D
Compensare presiune aerului automat automat automat
Memorie / Logger Inregistrare x manual 200 inregistrari manual 500 inregistrari
automat 5000 inregistrari
Interfata USB USB USB
Transfer de date format .csv (optional Excel) format .csv (optional Excel) format .csv (optional Excel)
Functii confermitate / valdiare GLP/AQA GLP/AQA GLP/AQA
Afisaj LCD cu display Grafic
Functionare continua 800 ore fara ecran iluminat / 100 ore cu ecran iluminat

Seturi de model / livrare

Model Continut / set Cod prod.
Oxi 3205 SET 3 Robust and waterproof portable dissolved oxygen meter for battery operation, case set with DurOx 325 and accessories 2BA103
Oxi 3210 SET 1 Robust and waterproof portable dissolved oxygen meter including memory, for battery operation, case set with CellOx 325 and accessories 2BA201
Oxi 3310 SET 1 Robust and waterproof portable dissolved oxygen meter including memory, data logger and USB mini B interface, for battery operation, case set with CellOx 325 and accessories 2BA301

Conformitate & Certificate
• Certificat de conformitate
• Marcat CE
• Certificat de garantie si post garantie MultiLab Romania
• Centru de service autorizat MultiLab Romania

Technical Features

Model Oxi 3205 Oxi 3210 Oxi 3310
Advantages - Suitable for CellOx or DurOx sensors
- Backlit graphic display
- Automatic air-pressure compensation
- Convenient user guidance
- Manual storage function
- For galvanic DO sensors
- Measures partial pressure, concentration and saturation
- Salinity corrections
- Storage for large measuring batches
- Waterproof USB interface for fast data transfer
- Data output in .csv format
- Calibration versus external standard possible (Winkler-titration)
- Measures partial pressure, concentration and saturation
- Salinity corrections
- Storage for large measuring batches
Measuring safety - Repeatable measuring results provided by the active, automatic AutoRead function with recognition of stable end values
- Safe operation: Automatic functions reduce the number of keys (6).
- OxiCal air-calibration
- Waterproof 8-pin socket for measurements in the field.
- Repeatable measuring results provided by the active, automatic AutoRead function with recognition of stable end values
- Automatic air-pressure compensation
- Silicone keypad with tangible key click, optional protective armor for field operation
- Repeatable measuring results provided by the active, automatic AutoRead function with recognition of stable end values
- Automatic air-pressure compensation
- Silicone keypad with tangible key click, optional protective armor for field operation
GLP/AQA documentation Transfer of all data in .csv format via USB interface to PC, on demand formatted transfer into Excel (MultiLab Importer, included in the delivery scope or as download). Storage with data output display or occasional documentation. Transfer of all data in .csv format via USB interface to PC, on demand formatted transfer into Excel (MultiLab Importer, included in the delivery scope or as download).

Technical Data

Model ProfiLine Oxi 3205 ProfiLine Oxi 3210 ProfiLine Oxi 3310
• Range / O2 Conc.
•• Resolution / O2 saturation
••• Accuracy O2 part. pressure
•••• Temperature
• 0.00 .. 20.00 mg/l (20.0 mg/l*) ±0.5 % of value; 0 .. 90 mg/l ±0.5 % of value
•• 0.0 .. 200.0 % (200 %*) ±0.5 % of value; 0 .. 600 % ±0.5 % of value
••• 0.0 .. 200.0 mbar (200 mbar*) ±0.5 % of value, 0 ... 1250 mbar ±0.5 % of value
•••• -5.0 .. +105.0 °C ±0,1 °C
Temperature compensation Better than 2% at 0 ... +40 °C
Air pressure compensation Automatic with built-in pressure sensor (500 .. 1100 mbar)
Salinity correction 0 or 35 fixed Automatic from 0.0 .. 70.0, adjustable via display
Calibration OxiCal rapid calibration in OxiCal-SL or OxiCal-D
Memory/Logger x Manual 200 manual 500
automatic 5000
Interface USB USB USB
Data Transfer .csv (optional Excel) .csv (optional Excel) .csv (optional Excel)
Documentation GLP/AQA GLP/AQA GLP/AQA
Display LCD cu display Grafic
Continuous operation Up to 800 hrs. without/100 hrs. with backlight

Ordering information

Model Delivery Order No.
Oxi 3205 SET 3 Robust and waterproof portable dissolved oxygen meter for battery operation, case set with DurOx 325 and accessories 2BA103
Oxi 3210 SET 1 Robust and waterproof portable dissolved oxygen meter including memory, for battery operation, case set with CellOx 325 and accessories 2BA201
Oxi 3310 SET 1 Robust and waterproof portable dissolved oxygen meter including memory, data logger and USB mini B interface, for battery operation, case set with CellOx 325 and accessories 2BA301



Senzori WTW pentru oxigen dizolvat

Model *Electrozi / Senzori de oxigen Cod prod.
StirrOx G Senzor de oxigen dizolvat cu agitator integrat pentru sticle tip Karlsruhe sau Winkler, include vas pentru stocare si calibrare "OxiCal–ST"
Self-stirring dissolved oxygen sensor for oxygen determination in Karlsruhe bottles and Winkler bottles, with OxiCal-ST calibration and storage vessel
201 425
CellOx 325 Senzor galvanic pentru oxigen dizolvat include vas de calibrare "OxiCal-SL" mufa cu cablu de 1.5 m lungime
Galvanic dissolved oxygen sensor with OxiCal-SL calibration and storage vessel, waterproof plug, cable length 1.5 m
201 533
DurOx 325-3 Senzor galvanic pentru oxigen dizolvat include vas de calibrare "OxiCal-D" mufa cu cablu de 3 m lungime
Galvanic dissolved oxygen sensor with OxiCal-D calibration vessel, waterproof plug, cable length 3 m
201 570

*Dissolved oxygen sensors (The sensor includes accessory case with spare parts and maintenance supplies)

Oxigenometre HANNA - SUA

conductometru_portabil_HI98192

Oxigenometru multifunctional

Model HI 98193

Aparat pentru masurarea oxigenul dizolvat cu barometru integrat

Professional Waterproof Dissolved Oxygen and BOD Meter


Pret : la cerere


Certificat de conformitate si validare


solicit oferta personalizata »

Specificatii tehnice
Oxigenometru portabil impermeabil HI 98193 este un instrument pentru masuratori de oxigen dizolvat, proiectat pentru a furniza citiri de mare acuratete atât în laborator cât si pe teren. Cu HI 98193 pot fi efectuate, pe lînga masuratorile de oxigen dizolvat si masuratori cu compensare de temperatura si salinitate exprimate ca BOD (Biochemical Oxygen Demand), OUR (Oxygen Uptake Rate) sau SOUR (Specific Oxygen Uptake Rate)
Aparatul este integrat cu un barometru pentru masurarea presiunii atmosferice si functie de calibrare folosind o unitate de masura selectabila de catre utilizator (mmHg, inHg, atm, mbar, psi, kPa)
Display de mare dimensiune cu nivele multiple de afisare si iluminare permite vizualizarea simultana a mai multor informatii precum valorile de oxigen dizolvat, presiunea, temperatura, ora si nivelul de încarcare a bateriei. Aparatul este impermeabil si permite inregistrarea datelor.

Date tehnice

DO :: Oxigen Dizolvat
Domeniu 0.00 la 50.00 mg/L (ppm); 0.0 la 600.0% saturatie
Rezolutie 0.01 mg/L (ppm); 0.1% saturatie
Accuratete (la 25°C) ±1.5% din citire ±1 digit
Calibrare automata, în 1 sau 2 puncte la 100% (8.26 mg/L) si 0 % (0mg/L);
manual într-un punct cu valoare setata de operator in % saturatie sau mg/L
Atmospheric Pressure
Domeniu 450 la 850 mmHg
Rezolutie 1 mmHg
Accuracy (la 25°C) ±3 mm Hg pana la ±15%de la punctul de calibrare
Calibrare intrun punct la orice valoare de presiune din domeniu
Temperature
Domeniu -20.0 la 120.0°C
Rezolutie 0.1°C
Acuratete (la 25°C) ±0.2°C (excluzand eroarea sondei)
Calibrare în 1 sau 2 puncte in la orice temperatura din domeniu
Caracteristici tehnice
Moduri de masurare direct DO; BOD; OUR; SOUR
Compensare barometrica automat de la 450 la 850 mmHg
Compensare de salinitate automat de la 0 la 70 g/L
Compensare termica automat de la 0.0 la 50.0°C
Sonda HI-764073 polarografica DO cu invelis de protectie, integrata cu senzor de temperatura, mufa tip DIN si cablu de 4m (inclus)
Inregistrare date - Logare pana la 400 de probe
Conectare PC USB optoizolat (cu software HI-92000 )
Tip baterie / Durata 4 baterii 1.5V AA / circa 200 ore de utilizare continua (fara iluminare) si 50 ore de utilizare cu iluminare
Inchidere automata reglabila de catre utilizator: 5, 10, 30, 60 min cu posibilitate de dezactivare
Conditii de operare 0 la 50°C; RH 100% IP67
Dimensiune 185 x 93 x 35.2 mm
Greutate 400g

Conformitate & Certificate
• Certificat de conformitate
• Marcat CE
• Certificat de garantie si post garantie MultiLab Romania
• Centru de service autorizat MultiLab Romania

Continut pachet: HI 98193 este livrat cu sonda pentru oxigen dizolvat HI 764073 cu senzor de temperatura încorporat si cablu de 4 m; 2 membrane de rezerva, 2 o-ringuri de rezerva; solutie electrolitica, solutie pentru calibrare zero oxigen, 2 pahare 100 mL, software HI 92000, cablu micro USB, 4 baterii 1.5V AA, geanta pentru transport si instructiuni de utilizare.

Main features
The HI-98193 portable dissolved oxygen meter has extended ranges of up to 50 ppm and 600% saturation. When measuring dissolved oxygen, compensations for salinity, temperature and pressure are essential to improve the accuracy and precision of readings
Salinity compensation allows for direct determination of dissolved oxygen in saline waters. Temperature compensation is automatic with the probes built-in sensor, which features a one or two-point calibration. Pressure compensation with the meter's built-in barometer can be validated against a reference barometer, and if needed, can be recalibrated in user-selectable units (mmHg, inHg, atm, psi, kPa, mbar). With the internal barometer, the HI-98193 is able to compensate for changes in barometric pressure so there is no need for charts, altitude information or external barometric pressure information.
Other features include measurement, methods and calculations for BOD, OUR and SOUR.
Advantages
- Quick connect probe The HI-764073 polarographic dissolved oxygen probe features a quick connect DIN connector to make attaching and removing the probe simple and easy
- Data Logging The HI-98193's log-on demand features allows users to store up to 400 samples that can be later transferred to a PC with the HI-920015 USB cable and HI-92000 software
GLP and On-Screen Help Comprehensive GL data is directly accessible by pressing the GLP key; the contextual help menu can be accessed to obtain on-screen information and assistance at the touch of a button.
Main Features
IP67 rated waterproof, rugged enclosure
Salinity compensation - users can set the salinity value
Automatic pressure compensation - built-in barometer with user-selectable units (mmHg, inHg, atm, psi, kPa, mbar)
Built-in calculations - determination of Biochemical Oxygen Demand (BOD), Oxygen Uptake Rate (OUR) and Specific Oxygen Uptake Rate (SOUR)
Automatic polarisation of probe at startup
Ready to use PTFE preformed membrane caps
Approximately 200 hours of continuous use
On-screen Features
BOD is calculated in mg per litre from the difference between the initial and final dissolved oxygen concentration readings
All necessary parameters for BOD testing can be set and displayed at once
A list of all saved BOD data can be easily retrieved and shown on the LCD display
OUR results measured in mg of oxygen consumed per L per hour
SOUR results measured in mg of oxygen consumed per g of volatile suspended solids per hour

Supplied with
- HI-764073 polargraphic DO probe
- HI-7040M
- HI-7041S
- Preformed PTFE membrane caps (2)
- DO protective cap
- O-rings (2)
- Rugged carrying case
- 100 mL plastic beaker (2)
- HI-92000 PC software
- HI-920015 micro USB cable
- Batteries
- Instruction manual
- Quality certificate

Technical Date

DO Dissolved oxigen
Range 0.00 to 50.00 mg/L (ppm); 0.0 to 600.0% saturation
Resolution 0.01 mg/L (ppm); 0.1% saturation
Accuracy (@25°C) ±1.5% of reading ±1 digit
Calibration automatic one or two point at 100% (8.26 mg/L) and 0 % (0mg/L); manual one point using a value entered by the user in % saturation or mg/L
Atmospheric Pressure
Range 450 to 850 mmHg
Resolution 1 mmHg
Accuracy (@25°C) ±3 mm Hg within ±15% from the calibration point
Calibration one point at any in range pressure value
Temperature
Range -20.0 to 120.0°C
Resolution 0.1°C
Accuracy (@25°C) ±0.2°C (excluding probe error)
Calibration one or two point at any in range temperature value
General Specifications
Measurement Modes direct DO; BOD; OUR; SOUR
Barometric Compensation automatic from 450 to 850 mmHg
Salinity Compensation automatic from 0 to 70 g/L
Temperature Compensation automatic from 0.0 to 50.0°C
Probe HI-764073 polarographic DO probe with protective sleeve, internal temperature sensor, DIN connector and 4m cable (included)
Logging log-on demand up to 400 samples
PC Connectivity opto-isolated USB (with HI-92000 software)
Battery Type/Life 1.5V AA batteries (4)/ approximately 200 hours of continuous use without backlight (50 hours with backlight)
Auto-off user-selectable: 5, 10, 30, 60 min or can be displayed
Environment 0 to 50°C; RH 100% IP67
Dimensions 185 x 93 x 35.2 mm
Weight 400g
