Dulapuri pentru depozitarea rezervoarelor de gaz comprimat sau lichefiat

dulapuri_gaze_lichefiate

ro Protectie si siguranta » Cabinete de siguranta » dulapuri de siguranta pentru bultelii si cilindri de gaz

uk Safety » Safety Storage Cabinets » Storage safety cabinets for compressed gas cylinders


Dulapuri stocare buteklii si cilindrii de gaz
Modele seria BG

Dulapuri de siguranta pentru depozitare cilindri de gaz omologate conform EN 14470-2 si DIN 12925-2

Safety cabinets for compressed gas cylinders


Pret : la cerere


Certificat de conformitate si validare


Made in EU


solicit oferta personalizata »



Model B60 B60X B120 B120X

Rezistenta termica la foc / timp 30 minute 90 minute 30 minute 90 minute
Nr.de compartimente 1 1 1 2
Dimensiuni externe (WxDxH) / mm 595 x 600 x 2050 595 x 600 x 2050 1200 x 600 x 2050 1200 x 600 x 2050
Dimensini interne (WxDxH) / mm 445 x 420 x 1760 445 x 420 x 1760 1050 x 420 x 1760 445 x 420 x 1760
445 x 420 x 1760
Nr. de usi 1 1 2 2
Capacitate 1 - 2 cilindri 1 - 2 cilindri 3 - 4 cilindri 1 - 2 cilindri x 2 (fiecare compartiment)
Rampa de rulare da da da da
Greutate 245 Kg 260 Kg 420 Kg 520 Kg
Cod produs B60G30 B60XG90 B120G30 B120XG90

Conformitate & Certificate
• Certificat de conformitate
• Marcat CE
• Certificat de garantie si post garantie MultiLab Romania
• Centru de service autorizat MultiLab Romania

Entirely built in electro-galvanized sheet steel with thickness of mm 1/1,5/2, bent with cold pressing with monolithic external structure varnished with anti-acid epoxy paint and passage into thermal gallery at 200°C.
Special insulation of calcium silicate (DIN 4102) releasing water molecules to lower the inner temperature in case of fire; Mineral wool panels for high temperatures (800°C)
Free from ceramic fiber fixed with ceramic bonding agent
Certification in compliance with new norm EN 14470-2
Safety lock with key
Certified automatic locking system (70/100°C) for air inlet and outlet piping
Non-sparking natural iron hinge with brass pin
Thermo-expanding gasket (DIN 4102)
Arrangement for piping passage
Closing sheet ramp for easy replacement of cylinders
Possibility of adjustable shelves for small cylinders (1 included).

Model B60 B60X B120 B120X
Fire class resistance / time 30 minute 90 minute 30 minute 90 minute
Nr.of compartiments 1 1 1 2
External dimension (WxDxH) / mm 595 x 600 x 2050 595 x 600 x 2050 1200 x 600 x 2050 1200 x 600 x 2050
Internal dimension (WxDxH) / mm 445 x 420 x 1760 445 x 420 x 1760 1050 x 420 x 1760 445 x 420 x 1760
445 x 420 x 1760
Nr. of doors 1 1 2 2
Capacity 1 - 2 cylinders 1 - 2 cylinders 3 - 4 cylinders 1 - 2 cylinders x 2 (each compartiment)
Closing sheet ramp yes yes yes yes
Weight 245 Kg 260 Kg 420 Kg 520 Kg
Product code B60G30 B60XG90 B120G30 B120XG90



- ATEX extraction system in metal box with electric system and power cable :: product code CSF125
- Daily timer :: product code TIM24
