Cuptoare universale multifunctionale pentru procese industriale


Cuptoare procese industriale
Tmp. maxima :: 900 °C si 1280 °C
Seria WM / ThermConcept - Germania

Cuptoare Boghiu cu vatra mobila » Temperatura maxima 1280 °C

Bogie-hearth Furnaces


produsul poate fi achizitionat si prin SEAP


Solicit oferta personalizata :: RFQ »

Caracteristici generale
Cuptoare din seria WM cu functionare discontinua, utilizate pentru detensionarea fortelor interne din structura metalica a produselor (pot fi si agabaritice in limita volumului cuptorului) in urma operatiei de sudare, cu control permanent al temperaturii pana la 1280°C.

Date Tehnice

Model Tmp. max. Volum Dimens.int Dimens.ext Putere Alimentare Greutate
WM 800/09 900 °C 800 lit. 900x1500x600 2350x2500x2650 32 kW 400 3/N 1300 Kg
WM 1000/09 900 °C 1000 lit. 900x2000x600 2350x3050x2650 40 kW 400 3/N 1500 Kg
WM 1500/09 900 °C 1500 lit. 1000x2500x600 2450x3500x2650 60 kW 400 3/N 2300 Kg
WM 2000/09 900 °C 2000 lit. 1000x2500x800 2450x3500x2900 80 kW 400 3/N 2800 Kg
WM 3000/09 900 °C 3000 lit. 1000x3000x1000 2650x4000x3250 110 kW 400 3/N 3600 Kg
WM 5000/09 900 °C 5000 lit. 1200x3000x1400 2700x4000x4500 130 kW 400 3/N 4300 Kg
WM 7000/09 900 °C 6700 lit. 1200x4000x1400 2700x5050x4500 150 kW 400 3/N 5000 Kg
WM 800/12 1280 °C 800 lit. 900x1500x600 2350x2500x2650 40 kW 400 3/N 1300 Kg
WM 1000/12 1280 °C 1000 lit. 900x2000x600 2350x3050x2650 60 kW 400 3/N 1500 Kg
WM 1500/12 1280 °C 1500 lit. 1000x2500x600 2450x3500x2650 80 kW 400 3/N 2300 Kg
WM 2000/12 1280 °C 2000 lit. 1000x2500x800 2450x3500x2900 110 kW 400 3/N 2800 Kg
WM 3000/12 1280 °C 3000 lit. 1000x3000x1000 2650x4000x3250 130 kW 400 3/N 3600 Kg
WM 5000/12 1280 °C 5000 lit. 1200x3000x1400 2700x4000x4500 180 kW 400 3/N 4300 Kg
WM 7000/12 1280 °C 6700 lit. 1200x4000x1400 2700x5050x4500 250 kW 400 3/N 5000 Kg

Conformitate - Certificate - Service
• Certificat de conformitate
• Certificat de garantie si post garantie
• Firma Multi-Lab este Certificata si Autorizata pentru comercializare, instalare si service produsele prezentate

Main features
Furnaces for temperatures up to 900 °C and 1280 °C
Robust case designs, double lined housing with rear ventilation » Very low outer casing temperature
Furnace door designed as hinged door » Simple, easy operation
Fitted with a door safety switch
Stable bogie-hearth with single-flanged rail wheels, including rails in front of the furnace
Heating elements in the bogie hearth covered with silicon carbide plates
Protection of heating elements, charging made easy by level support
With bottom damper and manually operated exhaust air flaps in the furnace top
High-quality, multilayer insulation made of refractory bricks featuring special rear insulation » Low heat loss, low power consumption
Heating from 5 sides (left, right, rear wall, door, bogie hearth) > Exceptionally uniform temperature distribution
High-quality heating elements » Long service life
Heating elements wound on ceramic tubes » Allows free radiation of heat into chamber, no heat accumulation

Technical Data

Model Max. Tmp. Volume Inner dimens. Outer dimens. Power Voltage Weight
WM 800/09 900 °C 800 lit. 900x1500x600 2350x2500x2650 32 kW 400 3/N 1300 Kg
WM 1000/09 900 °C 1000 lit. 900x2000x600 2350x3050x2650 40 kW 400 3/N 1500 Kg
WM 1500/09 900 °C 1500 lit. 1000x2500x600 2450x3500x2650 60 kW 400 3/N 2300 Kg
WM 2000/09 900 °C 2000 lit. 1000x2500x800 2450x3500x2900 80 kW 400 3/N 2800 Kg
WM 3000/09 900 °C 3000 lit. 1000x3000x1000 2650x4000x3250 110 kW 400 3/N 3600 Kg
WM 5000/09 900 °C 5000 lit. 1200x3000x1400 2700x4000x4500 130 kW 400 3/N 4300 Kg
WM 7000/09 900 °C 6700 lit. 1200x4000x1400 2700x5050x4500 150 kW 400 3/N 5000 Kg
WM 800/12 1280 °C 800 lit. 900x1500x600 2350x2500x2650 40 kW 400 3/N 1300 Kg
WM 1000/12 1280 °C 1000 lit. 900x2000x600 2350x3050x2650 60 kW 400 3/N 1500 Kg
WM 1500/12 1280 °C 1500 lit. 1000x2500x600 2450x3500x2650 80 kW 400 3/N 2300 Kg
WM 2000/12 1280 °C 2000 lit. 1000x2500x800 2450x3500x2900 110 kW 400 3/N 2800 Kg
WM 3000/12 1280 °C 3000 lit. 1000x3000x1000 2650x4000x3250 130 kW 400 3/N 3600 Kg
WM 5000/12 1280 °C 5000 lit. 1200x3000x1400 2700x4000x4500 180 kW 400 3/N 4300 Kg
WM 7000/12 1280 °C 6700 lit. 1200x4000x1400 2700x5050x4500 250 kW 400 3/N 5000 Kg
